Drive System (Tuff Torq)
Ref. Part Number Description
1. 918-05010 Transmission, Tu Torq K46
2. 710-0378 Hex Screw, 5/16-18, 2.50, Gr5, Std
3. 710-0599 Screw, Self-tapping, 1/4-20, 0.500
4. 710 - 0817 Screw, Self-tapping, 5/16-18, 1.250
5. 710-04484 Screw, Self-tapping, 5/16-18, .750
6. 710-3180 Hex Screw, 5/16-18, 1.75, Gr5
7. 710-1007 Screw, Self-tapping, 3/8-16, 1.500
8. 710 -1325 Screw, Self-tapping, 1/4-20, 1.625
9. 710 -3011 Hex Screw, 3/8-16, 2.25, Gr5
10. 912-0240 Nut, Jam, 7/16-20, Gr2
11. 914 - 0111 Pin, Cotter, 3/32, 1.0
12. 712-04063 Nut, Flange Lock, 5/16-18, Nylon
13. 912- 0431 Nut, Flange Lock, 3/8-16
14. 914 - 0111 Pin, Cotter, 3/32, 1.0
15. 725-05335 Jumper Harness, Ground & Reverse
16. 747-05447 Rod, Control, Tu-Torq
17. 747- 05448 Rod, Hydro Bypass
18. 747-05452 Rod, Brake, NX9 Tu-Torq
19. 750 - 05512 Spacer, .330 x .715 x .430
20. 954-04297 Belt, V-Type
21. 783-06849 Bracket, Mount, Tu-Torq
22. 783-07349 Bracket, NX9 Tu Torq
23. 783-07260 Bracket, Belt Keeper
24. 732-04792 Spring, Extension, 1.00 Dia x 4.75
25. 732-0716D Spring, Extension, .59 Od x 4.00
26. 710-1026 Screw, Self-tapping, 1/4-20 x 1.75
27. 936-0185 Washer, Flat, .375 x .738 x .063
28. 735 - 0 4118A Pad, Pedal, Forward
29. 735-04135 Pad, Pedal, Reverse
30. 936-0344 Wash, Flat, .385 x 1.00 x .030
31. 738-0430 Scr, Shldr, .50 x .685 3/8-16
Ref. Part Number Description
32. 736-0242 Washer, Bell, .340 x .872 x .060
33. 710-05339 Screw, 5/16-24 x .750
34. 738-04420 Spacer, Shoulder, 1.375 x .380 x .183
35. 736-0430 Washer, Flat, .350 x 1.59 x .062
36. 747- 04957A Rod, Transmission, Bypass
37. 750-04456 Spacer, .260 x .372 x 1.420
38. 756-04224 Pulley, Idler, Flat 2.75 OD
39. 731-2290A Cap, Hub
40. 938-0380 Bolt, Shoulder, .500 x .270, 3/8-16
41. 741-0495 Bearing, Flange, .630 x .695 x .60
42. 748- 04203 Latch, Cruise
43. 756-04325 Pulley, Idler, V-Type x 3.06
44. 783-06027B Bracket, Idler, Center Double
45. 783-05914 Bracket, Support, Pedal Strap
46. 783-05940 Bracket, Support, Pedal Strap 5/8
47. 783-06103A Bracket, Pedal, Brake
48. 647-04152D Control Assembly, Brake
49. 683-04488 Bracket Assembly, Pedal, Hydro
50. 710-0604A Screw, Self-tapping, 5/16-18, 0.625,
51. 711- 0 50 6 8 Pin, Clevis, 5/16 x 3.985
52. 712- 04065 Nut, Flange Lock, 3/8-16, Nylon
53. 714-04040 Pin, Cotter, Bow-Tie 72
54. 783-06059 Bracket, Pedal, Hydro
55. 726-0214 Cap, Push 5/8
56. 732-04587 Spring, Extension, .63 Dia x 4.95
57. 735-04136 Pad, Pedal, Brake
58. 731-05299A Sleeve, .765 Id x 1.500
59. 710-0216 Hex Cap Screw, 3/8-16 x .75
60. 783-07295 Bracket, Mount
61. 783-07347 Bracket, Belt
62. 783-07350 Bracket, Support
