48
Kawasaki FR691V-AS17 Cooling Equipment
Ref.
Part Number Description
13070 KM-13070-7019 Cooling Air Guide
13272 KM-13272-7006 Fan Plate
14037 KM-14037-70089H Screen
23062 KM-23062-7022 Complete Bracket
49089 KM-49089-7079 Engine Shroud
49089A KM-49089-7080 Engine Shroud
59041 KM-59041-7014 Fan
59066 KM-59066-7052 Fan Housing
92009 KM-92009-2303 Screw
92026 KM-92026-7007 Spacer
92151 KM-92151-7012 Bolt, 6 X 12
92153 KM-92153-7007 Bolt
92153A KM-92153-7043 Bolt, 6 X 12
