Cub Cadet LTX1050/KW User Manual

3
4
1
3
9
2
8
5
5
7
6
Ref. Part Number Description
1. 634-04406-0931 Wheel Ass’y, Complete, 15 x 6 x 6
2. 634-04405-0499 Rim Ass’y, 6.0 x 4.5, Plastic Bearings
3. 741-0990B Bearing, Flange, .760 ID w/ Fitting
4. 741-0516B Bearing, Flange, .760 x 1.00 x 1.20
5. 934-0255 Valve, Tubeless Air
6. 734-1731-0901 Tire, 15 x 6 x 6 Sq Shoulder
7. 634-0104-0931 Wheel, Complete, 20 x 8 x 8
— 634-0177-0931 Wheel Assy, Complete, 20 x 10 x 8
8. 634-04369-0499 Rim Ass’y, 8.0 x 7.0 x .750 ID
9. 734-1730-0901 Tire, 20 x 8 x 8 Sq Shoulder
— 734-1873-0901 Tire, 20 x 10 x 8 Sq Shoulder
Front and Rear Wheels
