51
Ref.
Part Number Description
13272 KM-13272-7012 Plate
21066 KM-21066-7017 Voltage Regulator
21171 K M -21171- 0711 Ignition Coil Assembly
21193 KM-21193-7038 Flywheel Assembly
26 011 KM-26011-7025 Lead Wire, L = 95
26031 KM-26031-7040 Harness
26031A KM-26031-7041 Harness
26031B KM-26031-7044 Harness
59031 KM-59031-7017 Charging Coil
92009 KM-92009-2303 Screw
Ref.
Part Number Description
92009A KM-92009-2308 Screw
92066 KM-92066-7026 Plug
92070 KM-BPR4ES Spark Plug
92072 KM-92072-7003 Band
92154 KM-92154-7003 Bolt, 12 X 30
92171 KM-92171-7008 Clamp
92172 KM-92172-7018 Screw, 5 X 20
92200 KM-92200-7002 Washer
130 KM-130AA0620 Flanged Bolt, 6 X 20
510 KM-510A5100 Woodru Key
Kawasaki FR691V-AS17 Electric Equipment
