Cub Cadet LTX1050/KW - Page 20

20
Hydrostatic Transmission (Hydro-Gear 311-0510)
Ref. Part Number Description
85 HG -51147 Hose, Expansion Tank
87 HG-51251 Cap,. Vent
88 HG-50653 Bolt, Self Tapping 10-32 x 112
94 HG-44147 Ball Bearing .62 Id x 1,38 x 44
95 HG-50837 Cap Screw, 5/16-24 x 1-112
96 HG -51200 Spacer, Locating
97 HG-50870 Screw, Sfhcs
98 H G -51120 Arm, Return
99 HG-51097 Puck, Adjusting
100 H G -51122 Washer, .325 OD x 1.6 ID x .150
101 HG -51131 Spring, Extension
102 HG -51123 Spacer, .56 x .26 x .87
103 HG -51223 Bracket, Torque
107 HG -51134 Deector
108 HG-51069 Washer, Motor Shaft .71 Id 1.15 Od
109 HG-9005110-5600 Plug, SAE #6
110 HG-50868 Torx Head Screw, 5/16-18
111 HG -5114 4 O-Ring, .07 x .301 ID
113 HG -51179 Bracket, Support Expansion Tank
114 HG -5118 4 Spring Guide
116 HG-70503 Silicon Sponge
120 HG-70759 Center Section - Bypass Assm
Center Section Machined
Base Filter w/ Poppet
Check Plug Assembly
Spring Bypass
Actuator Bypass
Deector
Bottom, Filter
Bushing, .707 x .788 x .591
Ref. Part Number Description
121 HG-70756 Filter Assembly
Bottom Filter
Base Filter w/ Poppet
Spring Bypass
Actuator Bypass
Deector
128 HG-70503 Kit, Expansion Tank
Tank, Expansion
Cap, Vent
Bolt, Self Tapping 10-32 x 1/2
Bracket, Support Expansion Tank
Silicon-Sponge 112 x 1/2 x 3/16
— HG-50928 Sealant
— HG-70463 Seal, O-Ring Kit
— — 20w-50 Oil (78.8 oz)
