Honda GC190LA Flywheel
FLYWHEEL
MAY, 2006 2006 American Honda Motor Co., Inc. 1-15
Z1A0E1900C
MODEL TYPE
A =GC190A a =MHA2
E-19
Engine
Serial Number
Ref Description From To QTY Part Number H/C
1 KEY, SPECIAL WOODRUFF (25X18) ........ -------- -------- 1 13331-357-000 0348433
2 COIL ASSY., IGNITION .............................. -------- -------- 1 30500-Z0J-003 6859722
3 FLYWHEEL ................................................ -------- -------- 1 31110-Z0J-013 7399538
5 WIRE, STOP SWITCH ................................ -------- -------- 1 32195-Z0J-000 6859730
6 HOLDER, STOP SWITCH WIRE ................ -------- -------- 1 36103-ZE1-000 1429141
8 BOLT, FLANGE (6X20) (CT200) ................ -------- -------- 1 90022-888-010 0671552
9 NUT, FLANGE (14MM)................................ -------- -------- 1 90213-S3Y-000 6352561
Ref. Part Number Description
1. 13331-357-000 Special Woodru Key, 25 x 18
2. 30500-Z0J-003 Ignition Coil Assembly
3. 31110 -Z0J - 013 Flywheel
5. 32195-Z0J-000 Stop Switch Wire
6. 36103-ZE1-000 Stop Switch Wire Holder
51125-Z0 L- 003 Stop Switch Wire Holder
8. 90022-888-010 Flange Bolt, 6 x 20
9. 90213-S3Y-000 Flange Nut, 14mm
