61
270-V0 Starter Assembly
Ref.
Part Number Description
108 710-04914 Bolt M6×10
109 951-11680 Flexible Clamp
110 951-11114 Switch Housing Mounting Brkt
111 712-04212 Nut,M6
112 710-04965 Bolt M4×55
113 710-05182 Bolt M6×32
114 715-04088 Dowel Pin 8×8
115 951-10645A Startup Electromotor
109
108
108
112
112
114
113
114
115
111
111
110
