10 se c t i O n 2— as s e M b l y & se t -up
Position Drive Control levers
The drive control levers of the tractor are lowered for shipping
purposes. The flange lock nuts, hex screws, and flat washers that
normally secure the control levers in their operating position
are unfastened and installed in the slotted holes of the control
levers for shipment. The control levers must be repositioned to
operate the tractor. To reposition the control levers for operation,
proceed as follows:
Remove the hex screw, flat washer, and flange lock nut from the
slot of one of the drive control levers.
Lift and swing that control lever upward until the slotted hole in 2.
the lever bracket aligns with one of the holes in the pivot
the hex screw with washer through the control lever slot
Note the relative position of the control lever to the pivot 4.
bracket, then repeat the previous steps to reposition the
other control lever in approximately the same position.
5.
adjustment of the levers.
Control Lever
Flange
Lock Nut
Slotted Hole
Washer
Hex Screw
Lift Control
Lever Upward
Pivot
Bracket
Figure 3-4
Connecting the Battery Cables
CALIFORNIA PROPOSITION 65 WARNING!
contain lead and lead compounds, chemicals known
reproductive harm. Wash hands after handling.
CAUTION: When attaching battery cables, always
For shipping reasons, both battery cables on your equipment
may have been left disconnected from the terminals at the
factory. To connect the battery cables, proceed as follows:
NOTE:
negative battery terminal is marked Neg. (–).
NOTE: If the positive battery cable is already attached, skip
ahead to step 2.
Remove the plastic cover, if present, from the positive battery
terminal and attach the red cable to the positive battery
Remove the plastic cover, if present, from the negative battery 2.
terminal and attach the black cable to the negative battery
help protect it from corrosion.
NOTE: If the battery is put into service after the date shown
on top/side of battery, charge the battery as instructed in the
the tractor.
Figure 3-5
