11se c t i O n 2 — as s e M b l y & se t -up
Lower Deck Discharge Chute Deflector
WARNING! Never operate the mower deck without
the chute deflector installed and in the down
position.
Check the mower deck for a shipping brace (with tag) that may
be holding the chute deflector upward for shipment. If a brace
is present, it must be removed before operating the tractor.
brace by grasping it and rotating it clockwise. Lower the chute
Figure 3-6
