PEDAL ASSEMBLY
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 647-0031B Control Assembly, Brake 1
2 647-0049A Control Assembly, Hydro 1
3 710-0726 Screw, Self-tapping, 5/16-12, 0.75 4
4 710-0650 Screw, Self-tapping, 5/16-18, 0.875 1
5 736-0119 Washer, Lock, 5/16 1
6 783-0773A Pedal, Brake 1
7 711-04159B Pin, 3/8-16, 3/8 x 2.68 1
8 712-04065 Nut, Nylon Lock, 3/8-16 2
9 712-3004A Nut, Flange Lock, 5/16-18, Gr5 1
10 714-0104 Pin, Cotter,.072 Dia. x 1.13 Lg 4
11 714-0111 Pin, Cotter, 3/32, 1.0 2
12 719-0584A Pedal, Hydro Control 1
13 732-0335 Spring, Compression,.405 x 1.17 1
14 732-0955 Spring, Extension,.50 OD x 1.41 Lg 1
15 732-0963 Spring, Extension,.50 Dia x 6.37 Lg 1
16 735-3049 Pad, Brake, Control 1
17 783-0663E Bracket, Lockout, Hydro 1
18 710-1611B Screw, Torx Hd. Tapp. 5/16-18 x.75 3
19 736-0187 Washer, Flat.64 ID x 1.24 x.06 2
20 736-3008 Washer, Flat,.344 x.750 x.120 1
21 738-0155 Shoulder, Screw.437 1
22 738-0380 Shoulder, Screw 3/8-16 1
23 741-0225 Bearing, Hex Flange 2
24 741-3065B Bearing, Hex Flange,.628 ID, Split 2
25 747-04096 Rod, Control, Cruise 1
26 747-04093 Rod, Control, Brake Lock 1
27 748-04039B Latch, Cruise 1
28 783-04612 Bracket, Support, Steering 1
