DESCRIPTION PAGE
Axle, Front ....................................................... 6
Battery ............................................................. 16
Brake Pedal ..................................................... 12
Deck, 54-inch.................................................... 20
Dash Panel ...................................................... 16
Drive System ................................................... 4
Engine .............................................................. *
Engine Accessories ......................................... 15
Fender ............................................................. 10
Frame .............................................................. 8
Fuel Tank ......................................................... 10
Head Lamp ...................................................... 18
Hood ................................................................ 18
Lift Linkage ...................................................... 11
Muffler .............................................................. 15
PTO ................................................................. 19
Seat ................................................................. 14
Steering ........................................................... 6
Transmission, Hydrostatic ............................... 22
Wheels, Front & Rear ...................................... 3
DESCRIPTION PAGE
SERIES 1500 HYDROSTATIC LAWN TRACTORS
TABLE OF CONTENTS
NOTE, For painted parts, please refer
to the list of color codes below. Please
add the applicable color code, wherever
needed, to the part number to order a
replacement part. For instance, if a part,
numbered 700-xxxx, is painted Cub
Yellow, the part number to order would
be 700-xxxx-0716.
Cub Yellow: 0716
Cub Beige: 0499
Powder Black: 0637
* Engine parts breakdowns unavailable at time of printing.
