Cub Cadet SLT1554 Parts Manual

21
54-INCH MOWER DECK
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 16606 Hook, Retainer Bracket 1
2 618-04129B Spindle Assembly 3
3 683-0254B Hanger Bracket Assembly 1
4 683-04079 Lift Shaft Assembly 1
5 683-04180 54” Deck Assembly 1
6 683-04182 Idler Arm Assembly 1
7 703-2093 Inner Rear Baffle 1
8 703-3279 Chute Deflector Stop 1
9 710-0216 Screw, 3/8-16 x.75 2
10 710-0520 Screw, 3/8-16 x 1.50 2
11 710-0528 Screw, 5/16-18 x 1.25 1
12 710-0599 Screw, 1/4-20 x.500 1
13 710-0623 Screw, TT, 3/8-16 x.750 4
14 710-0726 Screw, 5/16-12 x.750 15
15 710-1260A Screw, 5/16-18 x.750 12
16 710-3103 Screw, 5/16-18 x 2.00 1
17 710-3168 Bolt, Carriage, 3/8-16 x 1.00 1
18 710-3178 Bolt, Carriage, 3/8-16 x.750 2
19 711-1737 Pin, Roller,.5” Dia. x 10.06 Lg. 1
20 712-0206 Hex Nut, 12-13 2
21 712-0229 Push Nut, 3/8 2
22 712-04063 Nut, Flange Lock, 5/16-18 1
23 712-04065 Nut, Flange Lock, 3/8-16 9
24 712-0431 Nut, Flange Lock, 3/8-16 2
25 712-0641 Nut, Hex, M16-1.5 2
26 712-3010 Nut, Hex, 5/16-18 1
27 712-3022 Nut, Hex Lock, 1/2-13 1
28 712-3083 Nut, Hex Lock, 1/2-13 2
29 714-0111 Pin, Cotter, 3/32 x 1.00 1
30 714-0470 Pin, Cotter, 1/8 x 1.25 2
31 717-04074 Deck Adjustment Gear 1
32 721-04041 Water Nozzle Adapter 1
33 731-3005 Front Roller 1
34 732-0306A Sprg, Comprs,.531OD x 1.75 Lg. 2
35 732-0459B Spring, Ext.,.94 Dia. x 6.74 Lg. 1
36 732-0934 Spring, Ext., 1.15 Dia. x 5.99 Lg. 1
37 734-04039 Deck Wheel 4
38 736-0119 Washer, Lock, 5/16 1
39 736-0300 Washer, Flat,.406 x.875 x.059 2
40 736-0760 Washer, Lock 2
41 736-0921 Washer, Lock, 1/2 1
42 736-3084 Washer, Flat,.51 x 1.12 x.06 2
43 737-04003B Deck Water Nozzle 2
44 738-0373 Screw,.498 x 1.53 x 3/8-16 4
45 738-1229A Screw,.625 x 2.50 x 1/2-13 1
46 742-3013 Blade, High Lift, 18.5 Lg. 3
47 747-04384 Rod, Upstop 1
48 747-1116 Rod, Handle, Deck Release 2
49 747-1324 Rod, Deck, Front, Adj. 1
50 750-0151 Spacer,.550 ID x.755 OD x 1.1 2
51 754-04083 Belt, V, B Sec, 136.0 1
52 756-04129 Pulley, Idler, 4.25” Dia. 2
53 783-04013A Bracket, Stabilizer, Pulley 1
54 783-04462 Bracket, Lift 1
55 783-04690 Skirt, Deck 2
56 783-04691 Cover, Belt, RH 1
57 783-04692 Cover, Belt, LH 1
58 783-04726 Bracket, Idler, Stationary 1
59 631-04070 Chute Assembly, Side Discharge 1
60 783-04470 Chute Mounting Bracket 1
61 732-3070 Torsion Spring 1
62 731-3131A Deflector Chute 1
63 711-1762 Hinge Pin 1
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
