17
DASH PANEL
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0837 Screw, #10-16 x.625 1
2 710-0192 Screw, #10-24 x.375 2
3 710-0599 Screw, Self-tapping, 1/4-20, 0.500 6
4 710-0642 Screw, Hex. 1/4-20 x.75 2
5 736-0362 Flat Washer,.330 x 1.25 x.06 2
6 710-0703 Screw, Carriage, 1/4-20,.75, 1
7 710-0726 Screw, Hex, 5/16-12 x.75 12
8 710-0895 Screw, 1/4-15, 0.750 2
9 710-1611B Screw, Torx Hd. Tapp. 5/16-18 x.75 2
10 710-3217 Screw, Machine, #8-32, 0.375, Trus Phillips 1
11 712-0142 Nut, 8-32 1
12 712-0324 Nut, Nylon Lock, 1/4-20 1
13 747-04215 Strap, Battery 1
14 712-3087 Nut, Wing, 1/4-20 1
15 714-0104 Internal Cotter Pin,.072 x 1.13 1
16 710-04187 Screw, 1/4-15 x.50 1
17 731-05077 Dash 1
18 731-04294A Lever, Dash, Cruise 1
19 731-04293A Lever, Dash, Brake 1
20 731-3161 Knob, Throttle Control 1
21 783-04285B Dash Support, RH 1
22 710-04471 Ball Screw, 5/16-18 x.48 2
23 738-1132 Screw, Shoulder, 1/4-20,.25 x.15 1
24 783-04323B Dash Support, LH 1
25 746-04120 Control, Choke 1
26 747-1323A Rod,.250 Dia x 4.25 Lg. 1
27 783-04475 Bracket, Steering Support 1
28 783-04506A Plate, Dash Support 1
29 741-0587 Steering Column Bearing 1
30 783-0462 Bracket, PTO Switch Retainer 1
31 783-1447A Bracket, Support, Battery 1
32 712-3004A Flange Lock Nut,5/16-18 2
33 727-3194 Gas Spring Cylinder, 3.94 Stroke 2
34 783-1499 Bracket, Rod, Dash 1
35 725-1750A Battery, 235 CCA 1
36 712-0271 Nut, Sems, 1/4-20 1
37 725-04227 Switch Module, Ignition 1
38 725-04175 Switch, PTO, Yellow 1
39 725-04022 Monitor, Systems Indicator / Hour Meter 1
40 725-2054 Ignition Key, Plastic 2
41 746-1100 Control, Throttle, 38.0 1
42 736-0300 Flat Washer,.406 x.875 x.059 2
— 629-04139 Wire Harness 1
To Next Page
