7
STEERING
REF.
NO.
PART
NUMBER DESCRIPTION QTY.
1 710-0514 Hex Cap Screw, 3/8-16, 1.00, Gr5, Std 1
2 711-1408 Link, Drag, RH 1
3 711-1409A Link, Drag, LH 1
4 710-1260 Self-tapping Screw, 5/16-18 x.75 1
5 712-0240 Nut, Jam, 7/16-20, Gr2 2
6 712-0214 Nut, Hex, 3/8-24, Gr5 2
7 712-04065 Nut, Nylon Lock, 3/8-16 4
8 712-0459 Nut, Flange Lock, 7/16-20 1
9 712-3004A Nut, Flange Lock, 5/16-18 2
10 717-1550E Gear, Steering, 11/90 Ratio 1
11 717-1554 Gear, Pinion, Steering 1
12 723-0448A Ball Joint, 7/16-20 2
13 710-04095 Hex Cap Screw, 3/8-16, 1.00 1
14 736-3004 Washer, Flat,.406 x.875 x.105 1
15 736-3084 Washer, Flat,.510 x 1.120 x.060 1
16 737-3007 Grease, Alvania Ep 2 1
17 738-04154 Spacer, Shoulder, 1.00 x.38 x.38 2
18 738-04075 Shaft, Steering,.625 OD x 25.00 Lg 1
19 741-0475 Bushing, Plastic,.380 ID 2
20 741-0656A Bearing, Hex Flange, 5/8 1
21 683-04101 Axle Assembly, LH.750 Dia 1
22 683-04102 Axle Assembly, RH.750 Dia 1
23 712-0417A Nut, Hex, Flange, 5/8-18 2
24 714-04039 Pin, Cot, 5/32, 1.25 2
25 719-04105 Axle, Pivot, Cast.750 Dia 1
26 736-0866 Washer, Flat,.755 x 1.92 x.060 2
27 738-1011A Screw, Shoulder,.500 x 2.230, 3/8-16 2
28 731-04514 Wheel, Steering, Three Spoke 1
29 731-3210 Cover, Steering Wheel 1
