23
I. FUEL SYSTEM.
MAINTENANCE
1. Change the fuel pick up body every year.
2. Before storing your machine for a long period,
drain and clean the fuel tank and run the engine
until the carburetor is dry.
3. The fuel tank and the container in which the fuel
mix is stored should be cleaned from time to
time.
J. LUBRICATING THE GEAR HEAD.
Filler plug
1. Remove the filler plug.
2. Check the level and add grease, if necessary,
using a pressure pump. Leave about 5-10 g (1/4
oz.) for any expansion of grease.
NOTE:
Use a good quality lithium multipurpose grease.
DO NOT overfill the housing.
3. Tighten the filler plug firmly.
1. Pull the shaft out of the drive tube.
2. Use a good quality lithium multipurpose grease
to coat any dry areas of the shaft. Do not apply
too much grease. Never pump grease into the
drive tube.
K. LUBRICATING THE DRIVE SHAFT.
Drive shaft
Shaft
