4
1 IM-720113160 Shaft, Drive ....................... 1
2 IM-720124320 Pipe, Complete (Includes
6 Ref. 3) ............................ 1
3 IM-720133160 Metal ................................. 6
4 IM-720203082 Hanger .............................. 1
5 IM-720973178 Bolt, M6x14 ....................... 1
6 IM-720623400 Grip ................................... 1
7 IM-125034130 Lever Assembly, Throttle
(Includes 1 Ref. 8) ............ 1
8 IM-125504820 Wire Complete, Throttle .... 1
9 IM-720473180 Plate ................................. 1
10 IM-010709009 Bolt, M5x20....................... 6
11 IM-720043511 Deflector Assembly, Plastic
(Includes 1 Ref.12 and 13) 1
12 IM-720493060 Cutter ................................ 1
13 IM-010709008 Bolt, M5x16....................... 1
14 IM-720023990 Case Assembly, Gear
(Includes 1 ea. Ref. 15, 16,
17, 18, 19, 21, 22, 47, 48,
49 and 2 ea. Ref. 10 and
20) .................................... 1
15 IM-720973663 Bolt, M6x8......................... 1
16 IM-720973175 Bolt, M5x10....................... 1
17 IM-036500024 Snap Ring, R-24 ............... 1
18 IM-036100009 Snap Ring, S-9 ................. 1
19 IM-720973161 Bearing, Ball, 609ZZ ......... 1
20 IM-720973159 Bearing, Ball, 609 ............. 2
21 IM-040146001 Bearing, Ball, 6001LL ....... 1
22 IM-036500028 Snap Ring, R-28 ............... 1
23 IM-720333630 Holder ............................... 1
24 IM-720343890 Cover ................................ 1
25 IM-720333610 Holder ............................... 1
26 IM-720343780 Cover, Nut ......................... 1
27 IM-720973715 Nut, LH M10x1.25............. 1
Ref. Parts No.
No. No. Description Used
SHAFT, ST23 TRIMMER – PARTS LIST
28 IM-720053800 Handle, Loop (Includes
2 Ref. 29) .......................... 1
29 IM-720973177 Bolt, M6x12....................... 2
30 IM-720983371 Wrench, Spanner Box 19 . 1
31 IM-090500004 Wrench, Key, 4mm ........... 1
32 IM-720983420 Bag, Tool ........................... 1
33 IM-100814820 Manual, Operator’s ........... 1
38 IM-198113780 Rubber .............................. 1
39 IM-720973673 Bolt, 5x8............................ 1
40 IM-199233430 Collar ................................ 1
41 IM-026100005 Washer, 5mm.................... 1
47 IM-720263660 Case ................................. 1
48 IM-720273190 Gear Assembly ................. 1
49 IM-720293360 Shaft ................................. 1
Ref. Parts No.
No. No. Description Used
Optional
35 IM-195833140 Blade, 4 Tooth ................... 1
36 IM-195833170 Blade, 8 Tooth ................... 1
37 IM-195833230 Blade, Circular .................. 1
50 IM-720463430 Deflector, Steel ................. 1
51 IM-720053910 Handle Assembly, Loop
(Includes 2 Ref. 52) .......... 1
52 IM-720973183 Bolt, M6x18....................... 2
53 IM-720613420 Handle .............................. 1
54 IM-125034241 Lever Assembly, Throttle .. 1
55 IM-720623520 Grip Assembly .................. 1
56 IM-720063260 Holder Assembly, Handle . 1
57 IM-720973147 Coller ................................ 1
58 IM-720853461 Harness, Shoulder ............ 1
Ref. Parts No.
No. No. Description Used
