4
1 IM-720113120 Shaft, Drive ....................... 1
2 IM-720124290 Pipe, Complete (Includes 6
Ref. 3) ............................... 1
3 IM-720133061 Metal ................................. 6
4 IM-720203073 Hanger .............................. 1
5 IM-720973178 Bolt, M6x14 ....................... 1
6 IM-720623251 Grip ................................... 1
7 IM-125034150 Lever Assembly, Throttle
(Includes 1 Ref. 40) .......... 1
8 IM-720463430 Deflector, Steel ................. 1
9 IM-720473180 Plate ................................. 1
10 IM-010709009 Bolt, M5x20....................... 6
11 IM-720043511 Deflector Assembly, Plastic
(Includes 1 ea. Ref. 12 and
13) .................................... 1
12 IM-720493060 Cutter ................................ 1
13 IM-010709008 Bolt, M5x16....................... 1
14 IM-720023940 Case Assembly, Gear
(Includes 1 ea. Ref. 15, 16,
17, 18, 19, 21, 22, 45, 46
and 47 and 2 ea. Ref. 10
and 20) ............................. 1
15 IM-720973663 Bolt, M6x8......................... 1
16 IM-720973175 Bolt, M5x10....................... 1
17 IM-036500026 Snap Ring, R-26 ............... 1
18 IM-036100010 Snap Ring, S-10 ............... 1
19 IM-040126000 Bearing, Ball, 6000ZZ ....... 1
20 IM-040106000 Bearing, Ball, 6000 ........... 2
21 IM-040146001 Bearing, Ball, 6001LL ....... 1
22 IM-036500028 Snap Ring, R-28 ............... 1
23 IM-720333630 Holder ............................... 1
24 IM-720343890 Cover ................................ 1
25 IM-720333610 Holder ............................... 1
26 IM-720343780 Cover, Bolt ........................ 1
Ref. Parts No.
No. No. Description Used
SHAFT, ST35 TRIMMER – PARTS LIST
27 IM-720973715 Nut, LH M10x1.25............. 1
28 IM-720053650 Handle, Loop (Includes 2
Ref. 29) ............................. 1
29 IM-720973177 Bolt, M6x12....................... 2
30 IM-720853461 Harness, Shoulder ............ 1
31 IM-720983371 Wrench, Spanner Box 19 . 1
32 IM-090500004 Wrench, Key, 4mm ........... 1
33 IM-720983420 Bag, Tool ........................... 1
34 IM-100814820 Manual, Operator’s ........... 1
40 IM-125504820 Wire Compl, Throttle......... 1
45 IM-720263670 Case ................................. 1
46 IM-720273160 Gear Assembly ................. 1
47 IM-720293370 Shaft ................................. 1
Ref. Parts No.
No. No. Description Used
Ref. Parts No.
No. No. Description Used
OPtional
36 IM-195833150 Blade, 4 Tooth ................... 1
37 IM-195833070 Blade, 8 Tooth ................... 1
38 IM-195833160 Blade, Circular .................. 1
48 IM-720053910 Handle Assembly, Loop
(Includes 1 Ref. 49) .......... 1
49 IM-720973183 Bolt, M6x18....................... 2
50 IM-720613420 Handle .............................. 1
51 IM-125034241 Lever Assembly, Throttle .. 1
52 IM-720623520 Grip Assembly .................. 1
53 IM-720063260 Holder Assembly, Handle . 1
