Table 16. CSM Brinemaker Selection
Mineral Tank Brinemaker Size
Cubic
Ft.
Tank
Dia.
24 30 36 42
Total lbs. lbs./ft
3
Total lbs. lbs./ft
3
Total lbs. lbs./ft
3
Total lbs. lbs./ft
3
5 20 61.7 12.3 96.4 19.3 138.8 27.8 188.9 37.8
7 24 61.7 8.8 96.4 13.8 138.8 19.8 188.9 27.0
10 30 61.7 6.2 96.4 9.6 138.8 13.9 188.9 18.9
15 30 N/A N/A 96.4 6.4 138.8 9.3 188.9 12.6
20 36 N/A N/A N/A N/A 138.8 6.9 188.9 9.4
25 42 N/A N/A N/A N/A N/A N/A 188.9 7.6
30 42 N/A N/A N/A N/A N/A N/A 188.9 6.3
*Chart shows max salt dosage for DRY storage in total lbs and lbs/ft
3
Mineral
Tank
Brine Dia. 24 30 36 42
Max Load lbs 800 1200 1800 2400
Cubic Ft lbs./ft
3
Max
Load
#
regens
Max
Load
#
regens
Max
Load
#
regens
Max
Load
#
regens
5 6 800 26.7 1200 40.00 1800 60.00 2400 80.0
10 800 16.0 1200 24.00 1800 36.00 2400 48.0
15 500 6.7 1200 16.00 1800 24.00 2400 32.0
7 6 800 19.0 1200 28.60 1800 42.90 2400 57.1
10 524 7.5 1200 17.10 1800 25.70 2400 34.3
15 352 3.4 841 8.00 1800 17.10 2400 22.9
10 6 800 13.3 1200 20.00 1800 30.00 2400 40.0
10 376 3.8 866 8.70 1800 18.00 2400 24.0
15 619 4.10 1217 8.10 2400 16.0
15 6 426 4.7 1200 13.30 1800 20.00 2400 26.7
10 619 4.10 1217 8.10 2400 16.0
15 249 1.10 847 3.80 1554 6.9
20 6 278 2.3 767 6.40 1800 15.00 2400 20.0
10 372 1.90 970 4.90 1677 8.4
15 477 1.60 1183 3.9
25 6 619 4.10 1217 8.10 2400 16.0
10 723 2.90 1430 5.7
15 813 2.2
30 6 471 2.62 1069 5.94 2400 13.3
10 477 1.59 1184 3.9
15
=Wet Storage
