Performance Specifications
Culligan commercial water softeners are designed to remove hardness minerals from water. In order to function properly,
some operational parameters must be followed. They include:
• An operating pressure of water or air between 30 and 100 psi. If pressure is greater, a pressure regulating valve
should be installed ahead of the system. If pressure is lower, additional equipment will be required to maintain a 30
psi minimum operating pressure.
• Operating temperature between 40° and 120°F or 4.4° to 48° C.
• Clear (non-turbid) water supplies ( Less than 5 NTU )
Specifications Tables for CSM Series Water Softeners
*Allow a minimum of 24” clearance above the overall system height for access into top of tank(s).
1
Dimensions assume systems includes an optional, standard size brinemaker.
NOTE The tanks are available with Non-A.S.M.E. code steel tanks (NC) or with A.S.M.E. code steel tanks (CD).
Table 1. CSM Softener Flow Rates
Model Exchange Capacity
(kgr) Per Tank
Service Flow Rate (GPM) Per
Tank
Recommended
Minimum Flow
Rate (GPM) Per
Tank
Backwash
Flow Rate
(GPM) Per
Tank
Maximum
(grains)
Minimum
(grains)
Continuous
@ 15 psi max.
pressure loss
Peak @ 25
psi max.
pressure loss
150-2 150 100 67 94 3 10
210-2 210 140 76 102 4 13.5
300-2
300 200
84 112
5 20
300-3 152 210
450-2
450 300
79 106
8 20
450-3 135 192
600-2
600 400
94 125
10 30
600-3 183 252
750-2
750 500
97 129
13 45
750-3 201 267
900-2
900 600
96 127
15 45
900-3 193 259
