Culligan CTM 21 User Manual (English)

Questions and Answers:

K
Kayla PerezAug 17, 2025
Why is my Culligan Water Dispenser leaking at the pilot valve?
- S
  Samuel YoungAug 17, 2025
  If your Culligan Water Dispenser is leaking at the pilot valve, check if the leak is at the top clamp, valve manifold, or outer spool body, as this could indicate missing or damaged pilot spool body o-rings. Also, check the drain port on the valve manifold for damaged pilot spool o-rings. Finally, inspect the pilot spool shaft and inner pilot spool body for damaged pilot spool shaft o-rings.
L
linheidiAug 19, 2025
How to fix a slight leak to drain in Culligan CTM 21 Water Dispenser?
- J
  Jenna ThompsonAug 19, 2025
  To address a slight leak to the drain in your Culligan Water Dispenser, first, disconnect the pilot valve tubing at the drain port on the valve if the flow from the tubing indicates a leaky seal in the pilot valve spool. If the pilot valve is not leaking, use a test kit to check for hard water at the drain, which could indicate missing or damaged piston/cap O-Rings or T-Seal.
W
William ClineAug 22, 2025
Why is there restricted or no service flow in my Culligan CTM 21 Water Dispenser?
- H
  Hannah RodriguezAug 22, 2025
  If your Culligan Water Dispenser shows restricted or no service flow, it could be due to several reasons. Either the service inlet or outlet piston isn't opening fully. Try turning the pilot to position #2 to determine which one is the issue. It may also be caused by failed distributors or contamination of the resin bed, potentially indicating clogged distributors or a compacted media bed. Another possible cause is water pressure below 35 psi, so check the feed water pressure.
L
Logan PaulAug 26, 2025
What to do if unfiltered water leaks into the service lines of my Culligan CTM 21?
- E
  Elizabeth JohnsonAug 26, 2025
  If you notice unfiltered water leaking into the service lines of your Culligan Water Dispenser, inspect the bypass piston. The issue could be a plugged pilot strainer (if there's no flow from the tubing), a dirty, worn, or loose T-Seal, an eroded seat, a torn upper piston o-ring, or build-up inside the valve cavity preventing the piston assembly from seating.
T
Tracy PhillipsAug 28, 2025
Why doesn't the pilot pressurize or vent valve ports properly in my Culligan CTM 21?
- M
  Michael AndersonAug 28, 2025
  If your Culligan Water Dispenser's pilot doesn't pressurize or vent valve ports properly, start by checking the screen on the pilot strainer, as a clogged screen can prevent control pressure from reaching the pilot valve (and solenoid valves, if applicable). If water flows out of the tubing, check the fitting in the valve inlet port and pilot valve strainer for any obstruction. Also, remove the external plumbing connections and clamp, then remove the valve body from the tank adapter and lay the valve body on its side. Finally, if the piston function does match Table 9, check for missing or damaged coupling o-rings, piston o-rings or refill piston spring.
D
David OwensAug 30, 2025
What to do if the piston does not open in my Culligan CTM 21?
- H
  hollandzacharyAug 30, 2025
  If the piston in your Culligan Water Dispenser does not open, it might be due to a fouled or swollen T-Seal. To resolve this, turn off the water pressure, remove the clamp, disconnect the external plumbing, and then remove the valve body from the tank adapter. Visually inspect the T-Seal for any damage or swelling.
S
sandersconnieSep 2, 2025
What to do if the piston does not close or open in my Culligan CTM 21 Water Dispenser?
- A
  Anna JohnsonSep 2, 2025
  If the piston in your Culligan Water Dispenser doesn't close or open, you can try the following: First, turn off the water pressure, remove the spool manifold, and then remove the piston from the control valve. If there is no flow from the tubing, the pilot strainer may be plugged, the T-Seal may be dirty, worn, or loose, the seat may be eroded, or the upper piston o-ring may be torn.
E
Eileen CruzSep 5, 2025
Why doesn't my Culligan Water Dispenser's filter tank remain in standby mode?
- N
  nicoleschmidtSep 5, 2025
  If your Culligan Water Dispenser's filter tank does not remain in standby mode or does not provide water through the outlet of the control valve when in service, verify the operation of the motorized ball valves of the control valve. The issue might stem from the motorized ball valve not being properly wired or water hardness scale build-up inside causing a malfunction.
D
Dawn McfarlandSep 7, 2025
What to do if there is high flow to drain during service in my Culligan Water Dispenser?
- J
  James TuckerSep 8, 2025
  If you experience high flow to the drain during service with your Culligan Water Dispenser, check the position dial pilot. Also, use a test kit to check the hardness of the water at the drain. If the water pressure is less than 35 psi, check the feed water pressure.
J
John PettySep 12, 2025
How to troubleshoot restricted or no drain flow during backwash in Culligan CTM 21?
- A
  Alex JonesSep 12, 2025
  To troubleshoot restricted or no drain flow during backwash in your Culligan Water Dispenser, turn the pilot to position #2 and then to position #4, comparing the rate of flow to the drain.
