8 Culligan® Culligan Top Mount (CTM) Water Filters
8 Cat. No. 01029343
Mount the Valve
Figure 6.
1. Position and
lubricate large
o-ring above
threads.
2. Lubricate small o-ring
3. Attach upper disperser by snap-
ping into the slots in the tank
adapter. Making sure, that it is
secured.
4. Twist the valve onto the
tank, counterclockwise
to the thread start. Twist
clockwise, handtight, until
the large o-ring is fully com-
pressed in the tank.
NOTE Tank may need to be rotated for
preferred positioning.
CAUTION! Do Not Overtighten!
