Installation 9
Cat. No. 01029343
Plumbing Adapter
Figure 7.
Insert pins into the valve body and adapter
Flow Meter
(Second coupling in
Timeclock models)
Lubricate o-rings
Lubricate o-rings
Coupling
1.5” or 2” Threads
Insert Plumbing Adapter
CAUTION! All sodering must be done on any
connections requiring soldering prior to
connecting the main control valve. The
main control valve will be damaged if it is
connected at the time of soldering.
