Culligan CTM 21 - Mounting the Controller

Installation 19
Cat. No. 01029343
Mounting the Controller
Valve Front Mount (Provided in Sizing Kit)
Figure 16. Controller Valve Front Mounted
Wall Mount (Optional)
Figure 17. Controller Wall Mounted (Not Actual Size)
144” Meter’s Wire Harness (P/N 01017176)
144”
8.75”
4”
144”
144” Wire Harness (P/N 01029491)
