Culligan CTM 21 - General Troubleshooting

Service and Repair 53
Cat. No. 01029343
Motor Replacement (P/N 01029558, if only replacing the motor assembly)
Figure 72.
Figure 73.
Motor Bracket
Remove #2 Screw and Motor Gear
Replace with new motor
Remove #2
Screws
Ensure gears are
engaged between
motor and spool body
