Final Startup 35
Cat. No. 01024821
To use Table 8 locate the resin volume of the softener model along the left side of the table. Select a 6, 10 or 15 pound/
cubic foot of resin salt dosage amount. Continue reading the table to the right until you find a brine system that provides
the salt storage characteristics desired. Refer to the key at the bottom of the chart for information concerning the shaded
areas of this table
Table 8. High Efficiency 1.5 Twin brine tank data, 1/2” valves.
1/2" Brine Valve Size
Mineral
Tank
Brine Dia 18 24x40 24x50
Max Load lbs 375 600 900
Cubic Feet lbs/ft³ Max Load # regens Max Load # regens Max Load # regens
2
6 375 31.3 600 50 900 75
10 375 18.8 600 30 900 45
15 375 12.5 600 20 900 30
3
6 375 20.8 600 33.3 900 50
10 375 12.5 600 20 900 30
15 267 5.9 600 13.3 900 20
4
6 375 15.6 600 25 900 37.5
10 292 7.3 600 15 900 22.5
15 193 3.2 600 10 900 15
5
6 375 12.5 600 20 900 30
10 243 4.9 600 12 900 18
15 119 1.6 500 6.7 500 6.7
7
6 282 6.7 600 14.3 900 21.4
10 144 2.1 524 7.5 524 7.5
15 352 3.4 352 3.4
XXX = wet storage (for more information regarding wet storage, see page 34)
= brine system or dosage not recommended for softener
Key for Table 9 on the Next Page
Column Name Description
lbs/ft
3
= Salt Usage
Dos. = Salt Dosage
Cap. = Capacity
XXX = wet storage (for more information regarding wet storage, see page 34)
To Next Page
