58 Culligan® High Efficiency 1.5 Twin Water Softener
58 Cat. No. 01024821
HE 1.5 Twin Control Valve Parts List
Item Part No. Description
01031601 HE 1.5 Control Valve, Complete
01031604
HE 1.5 Twin Control Valve #2,
Complete
1 01031628 Body Chambers, Welded, 1.5"
2 01031428
Piston Rebuild Kit, Includes 6ea Pis-
ton assemblies and 1ea Brine Piston
Assembly
3 P1025242
Brine Piston w/80 Duro Quad Seal, HE
1.25” - HE 1.5”, 5ea
5 01031620 Gear Box Assembly
6 01024332 Gearmotor
7 P1020415 Retainer, Gearmotor, 10ea
8 —
Wire Harness w/ Position Sensor (not
available for sale), Kit
8* —
Wire Harness w/ Position Sensor, Ex-
tended, Control #2 (not available for
sale), Kit
9 01022735 Wire Harness, Motor, HE
10 01025493 Wire Harness, Motor, HE, Extended
11 P1020433 Position Sensor Screw, 10ea/Kit
12 P1023546 Gear Box Assembly Screw, 10ea
13 P1020289 Dial-a-Softness Knob, 10ea
14 P1022185
Dial-a-Softness Assembly w/ O-Rings,
10ea
15 P1020487 Plug Assy, Eductor Housing, HE, 10ea
16 P1020290 Eductor Plug Retainer, 10ea
17 P1020489 Plug, Backwash Assy, 10ea
18 P1020291 Backwash Bypass Retainer, 10ea
19 P1024022 Drain Straight Fitting Assembly, 5ea
20 P1023021 Drain Elbow Assembly, 10ea
23 01030232
Frame, Hood, Compact, HE Control,
Outdoor
24 P1030127 Retainer, Brine & Drain Elbow, 10ea
25 01030232
Cover, Hood, Compact, HE 1½"
Control, Outdoor
26 P0440268 O-Ring, Brine & Drain Elbow, 10ea/Kit
27 P0401031 Backwash Flow Control, 5.5 gpm, 10ea
27 P0708008 Backwash Flow Control, 7 gpm, 10ea
27 P0708011 Backwash Flow Control, 11.5 gpm,10ea
28 P0318383 Enclosure Screw, 10ea/Kit
29 P1023122 Retainer for Enclosure Screw, 10ea/Kit
31 P1025274 Strain Relief Fitting, 10ea
32 P1025277 Liquid Tight Hole Plug, 10ea/Kit
34 —
Compartment Plate w/ Gaskets (not
available for sale), Kit
35 P1025278 Bushing, Strain Relief, 10ea/Kit
36 —
Enclosure w/ Decal and Keyboard (not
available for sale), Kit
38 01017134 Power Cord
39 01023550
Connector, Plumbing, 1½" NPT,
Control 1½"
40 01020745 Replacement Circuit Board
41 —
Enclosure w/ Decal (not avail. for sale),
Kit
42 01025650
Electronics Enclosure Kit w/o Circuit
Board
Item Part No. Description
43 01025652
Electronics Enclosure Kit, Twin, Con-
trol #2
45 P1022796
Eductor Throat with O-rings, Downflow,
Beige, 10ea
45 P1022723
Eductor Throat with O-rings, Downflow,
Blue, 10ea
46 P1020603 Eductor Throat O-ring, Large, 10ea/Kit
47 P1020428 Eductor Throat O-ring, Small, 10ea/Kit
48 P1013895 Eductor Nozzle w/ O-ring, Beige, 10ea
48 P1024333 Eductor Nozzle w/ O-ring, Green, 10ea
48 01014253 Eductor Nozzle w/ O-ring, Yellow
49 P0308438 O-ring, Eductor Nozzle, 10ea/Kit
50 P1029422 Screen, 10ea
51 01019742 Disperser
52 P1023558 Retaining Ring, 10ea
53 P1023560 O-ring, Manifold, 10ea
56 P1024364 Large Piston, O-ring, 25ea/Kit
57 P1025239 Large Piston Quad Ring, 25ea/Kit
60 P1020431 Small Piston, O-ring, 25ea/Kit
61 P1025199 Small Piston Quad Ring, 25ea/Kit
62 P1020426 Brine Piston O-ring 25ea/Kit
63 —
Brine Piston Quad Ring (not available
for sale), Kit
64 P1020252 Main Piston Spring, 10ea
65 P1020286 Brine Piston Spring 10ea
70 P1009075 Retaining Clip, 10ea/Kit
71 01014033 Coupling Kit
72 P1009099 O-ring, Couplings/Meters, 50ea/Kit
73 P1023200 Screw, Compartment Plate, 10ea/Kit
74 01025282 Harness, Meter, 28” Long, Outdoor
82 01026849 Meter Kit Assembly, HE 1”, LF
83 01025490
Harness, Meter, 48" Long, Two Con-
nectors, Outdoor
86 01024788
Interconnecting Tank Assembly (14"
and 16" Tanks)
86 01024789
Interconnecting Tank Assembly (18"
and 21" Tanks)
87 P1021162 O-ring, 10ea/Kit
88 P1020424 O-ring, 10ea/Kit
* P0451701 Hose Clamp, Drain, 10ea
* P1023559 O-ring, Valve to Tank, 10ea
* 01014897 Transformer, Dual Output
* 01020620
Transformer, Dual Output w/ 6' Power
Cord (optional)
* P0443494 Adapter, 1/2" Tube X 1/2" NPT, 10ea
* P0440516 1/2" Tube Insert, 25ea
* P1024720 1/2" Tee, 10ea
* 01024216
1½" Bypass Valve (includes Bypass
Piston)
* P1014426 Backwash Flow Control, Spacer, 10ea
* 01025281
Replacement Bypass Piston for HE
1.25/1.5
* 01025561
Transformer, Outdoor, 24V, HE Com-
pact Hood
*Not shown in diagram
To Next Page
