Troubleshooting 67
Cat. No. 01023552
Up Flow Regeneration—Brine Draw
Raw water is directed from the inlet through the nozzle and into the throat. A vacuum is created and concentrated brine
is educted (drawn). The raw water and concentrated brine combine, enter the mineral tank, and pass through the resin,
up the manifold and to the drain. Once all of the brine has been educted and the brine valve seats, the unit goes into slow
rinse. Hard water is allowed to service during regeneration.
P1
P6
P4
P2
P3
P5
PR
Raw
Water
Bypassed
Water
To
Drain
To
Brine
Tank
Tank
Inlet
Tank
Brine
Piston
Hard Water
Softened Water
Drain
Brine
Diluted Brine
Figure 75. Up flow regeneration—brine draw.
Brine Draw
Piston Position
P1–Inlet Closed
P2/3–Outlet Closed
P4–Backwash Open
P5–Rinse Closed
P6–Bypass Piston Open
Brine Piston Open
PR–Refill Piston Closed
