Service Parts 77
Cat. No. 01023552
24"x50" Brine System
1
3
2
5
4
6
7
8
Figure 84. 24”x50” brine system.
Item Part No. Description Qty
01024638 24"x50" Brine System Complete, 0.8 gpm, 1/2" Connection, 0.8 BLFC (includes items 1 - 8)
01024666 Tank w/Well and Cover (includes items 1 - 7)
1 Tank 1
2 Cover 1
3 01019623 Salt Plate, 24" 1
4 01019621 Brine Well 1
5 01019622 Brine Well Cap 1
6 Bushing, 3/4" x 1" NPT 1
7 Elbow, 1" NPT x 1" Socket 1
8 01024634 Brine Valve, 1/2" Connection, 0.8 gpm, BLFC 1
