Culligan M1 Series User Manual

M1 RO Parts Diagrams and Lists 45
Cat. No. 01022940
M1 RO Series 1S 2S 3S 4S 2L 3L 4L 1F 2F
Item Part No. Description Qty Qty Qty Qty Qty Qty Qty Qty Qty
1 01024485 Motor Panel Assembly, M1-1S, M1-
2S, M1-3S, M1-4S
1 1 1 1
1 01024504 Motor Panel Assembly, M1-2L, M1-3L 1 1
1 01024505 Motor Panel Assembly, M1-4L 1
1 01024506 Motor Panel Assembly, M1-1F, M1-2F 1 1
2 01021992 Assembly, Feed 1 1 1 1 1 1 1 1 1
3 01021993 Assembly, Return 1 1 1 1 1 1 1 1 1
4 01022053 Assembly, Drain 1 1 1 1 1 1 1 1 1
6 01021997 Assembly, Pressure Gauge 1 1 1 1 1 1 1 1 1
7 01022855 Pump, Rotary Vane, Brass, 100 GPH 1 1 1 1
7 01023798 Pump, Rotary Vane, Brass, 165 GPH 1 1
7 01023800 Pump, Rotary Vane, Brass, 190 GPH 1
7 01022106 Pump, Rotary Vane, Brass, 330 GPH 1 1
8 01022856 Motor, 1/3 HP, 115V, 1725 RPM,
Nema Frame 48Y, Carbonator Mount
Style
1 1 1 1
8 01022107 Motor, 3/4 HP, 115V, 1725 RPM,
Nema Frame 48Y, Carbonator Mount
Style
1 1 1 1 1
— 01022033 V-band, Pump/Motor 1 1 1 1 1 1 1 1 1
10 01025339 Flow Meter, 0.1–1 gpm, Panel Mount 1 1 1 1
10 01025340 Flow Meter, 0.35–3.5 gpm, Panel
Mount
1 1 1 1 1
11 01025480 Filter Housing, 10" BB 1 1 1 1 1 1 1 1 1
12 01022387 Cartridge Filter 1 1 1 1 1 1 1 1 1
15 01024455 Bracket Kit, Wall Mount 1 1 1 1 1 1 1
15 01024484 Bracket Kit, Wall Mount 1 1
16 01023412 Assembly, Membrane Housing, Sin-
gle, 2.5"x21"
1 2 3 4
16 01023417 Assembly, Membrane Housing, Sin-
gle, 2.5"x40"
2 3 4
16 01022875 Assembly, Membrane Housing, Sin-
gle, 4.0"x40"
1 2
17 01024478 Controller, CP+, complete 1 1 1 1 1 1 1 1 1
— 01024139 Circuit Board, CP+ 1 1 1 1 1 1 1 1 1
WARNING! The 115/230V Voltage Selector Switch must be set at the appropriate voltage. Setting
the CP Plus board to incorrect voltage will cause permanent damage to equipment.
WARNING! Motors must be wired to the appropriate voltage and Hz. Connecting to incorrect
voltage will cause permanent damage to equipment.
