Culligan M1 Series User Manual

44 Culligan® M1 Series Reverse Osmosis
44 Cat. No. 01022940
M1 RO Parts Diagrams and Lists
M1 Major Components and Water Connections
10
1
6
16
17
12
11
2
4
15
Figure 26. M1 RO front view.
3
8
7
System Inlet
(1/2" Tube)
From Membrane
Concentrate (3/8" Tube)
Return Assembly Tube
Pressure Gauge Tube
To Membrane Feed (1/2" Tube)
System Waste Concentrate (3/8" Tube)
From Membrane
Product Tube (1/2" Tube)
System Product Water (3/8" Tube)
Figure 27. M1 RO rear view.
