M1 RO International
59
Cat. No. 01022940
CP Plus Circuit Board 230V
WARNING!
The 115/230V Voltage Selector Switch must be set at 230V. Setting the CP Plus board
to incorrect voltage will cause permanent damage to equipment.
RUN NOW
Push Button
Connector
High V
oltage
Te
rminals
1
15V/230V V
oltage
Selector Switch
Connection
for Optional
TDS Probe
Dry Contact
Te
rminals
Fuse: 250 V
AC 125 mA,
5mm x 20mm
GREEN/YELLOW
BLUE
BROWN
BROWN
BLUE
BROWN
BLUE
Figure 4
1
.
CP Plus circuit board configured for 230 VAC.
62
64
Table of Contents
Table of Contents
3
Introduction
5
Features
6
M1 Series Specifications
7
Unit Configurations
8
M1 RO Installation
9
Operation
25
Initial Startup
26
Accessories
33
Service and Maintenance
34
Flow Diagram
46
Wiring Diagram
47
M1 RO Parts Diagrams and Lists
48
Appendix A M1 RO International
62
Appendix B Basic Principles
79
Index
82
