38 Culligan® Series M2 Reverse Osmosis
38 Cat. No. 01023095
Feed Flow Meter Product Flow Meter
Model FM1 Initial Nozzle Needed/K Factor FM2 Initial Nozzle Needed/K Factor
2 87 91
3 87 91
4 87 91
5 87 91
6 87 91
Table 2. K factor for FM1 and FM2.
9. Calculate the values for “A” and “B” using the following equations:
FM1 =
(FM1 INITIAL) x (FFLOW DISPLAYED)
FFLOW ACTUAL
Where
FM1 INITIAL is
FFLOW DISPLAYED is displayed on the GBE RO controller
FFLOW ACTUAL = (Actual Product Flow) + (Actual Waste), in gallons per minute
FM2 =
(FM2 INITIAL) x (PFLOW DISPLAYED)
PFLOW ACTUAL
Where
FM2 INITIAL is
PFLOW DISPLAYED is displayed on the GBE RO controller
PFLOW ACTUAL = (Actual Product), in gallons per minute
10. Verify that the displayed values on the GBE RO controller match the actual values.
11. The measured/calculated flow rates should be verified at the target flow rates. If not, repeat this procedure.
RUNNING
JAN-01-12 12:01P
1. From the default home screen, press . The screen displays the main menu.
1) GO TO RUNNING
2) GO TO OFFLINE
3) INFORMATION
>4) SETUP
2. Press to scroll to 4) SETUP.
3. Press to select the SETUP menu.
2) LANGUAGE
3) POWERON MODE
4) FLUSH MODES
>5) ACCESSORIES
4. Press to select 5)ACCESSORIES. The screen displays the ac-
cessories menu.
1) WIRELESS REM
2) MODEM
>3) FLOW METERS
4) SWITCH INPTS
5. Press to select 3)FLOW METERS. The screen displays the flow meter
settings.
