Diesel Engine Complete Engine
80
Lubricating Oil Filter
Install the lubricating oil filter.
NOTE: Some engines will have an oil filter cooler
mounted between the oil filter and the
engine block.
Block Water Heater
Clean the core plug hole thoroughly. Make sure there
are not burrs or sharp edges that might cut the o-ring.
Lubricate the new heater o-ring with clean engine oil.
The locking channel (T-Bar) should be threaded out
to the end of the bolt. If so equipped, do not remove
the retaining wire used to position the channel (T-Bar).
cs9pxea
00900155
cs9orwa
cs900wg
