Curtis 700 series - Model Encodement (732 Series Only); Case Specifications; Function Specifications; LED Voltage Specifications

4 5
Example: 732 N 2 3 001 N
Function
Case
Style
LED
Voltage
Sequential
Code
1 3 5
2 4
Logo
Function
1
2
0 2-wire Hour Meter, no enable; LED gnd-enabled, no reset.
1 2-wire Hour Meter, no enable; LED pwr-enabled, no reset.
2 2-wire Hour Meter, no enable; LED gnd-enabled, w/reset.
3 2-wire Hour Meter, no enable; LED pwr-enabled, w/reset.
4 3-wire Hour Meter, w/enable; LED gnd-enabled, no reset.
5 3-wire Hour Meter, w/enable; LED pwr-enabled, no reset.
LED Voltage (VDC)
3
0 12
1 24
2 36
3 48
Case Style
See section 2.2 for complete specifications.
5
732 Model Encodement Only
Note: 732 has a built-in LED in its face
4
Sequential Code
Factory specified.
O Curtis
N None
Logo
