Curtis 700 series Manual

10 11
Case Bezel Shape Terminals Max Pins Mounting Lens Matrl. Case Matrl. Bezel Material Panel Cutout (mm) Panel Cutout (in.)
F Hexagonal 1/4” Faston 4 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
G Hexagonal Packard 2 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
J Hexagonal Packard 4 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
K Hexagonal Packard 4 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
N Hexagonal 1/4” Faston 4 Flange Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
D Rect. - DIN 3/16” Faston 4 U-Bracket Acrylic ABS (black) ABS (black) 45x22.2 1.77x0.87
L Rectangular Molex-mini 4 Snap-In Plycarb. Polycarb. Polycarb. 36.8x24.1 1.45x0.95
H Rectangular Packard 2 Bracket (plast.) Acrylic ABS (black) Acrylic (clear) 36.8x24.1 1.45x0.95
Y Rectangular Packard 4 Bracket (plast.) Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
Z Rectangular 1/4” Faston 4 Bracket (plast.) Acrylic ABS (black) ABS (black) 36.8x24.1 1.45x0.95
Q Round 1/4” Faston 4 U-bracket Glass Polycarb. Alum. Anodzd. (blk) Ø 52 Ø 2 1/16”
R
(5mm) Round 3/16” Faston 4 U-bracket Glass Polycarb. Alum. Anodzd. (blk) Ø 52 Ø 2 1/16”
NOTE:
K & N – LED indicator molded in bezel face (available as 732 models only);
G & H – Require 2-pin Delphi- Packard mating connector P/N 12162000;
J, K & Y – Require 4-pin Delphi- Packard mating connector P/N 12162035;
L - Snap tabs built in(no mounting hardware required); case and bezel 1-piece clear
Hexagonal - Screw mount through flange (optionally mounted with plastic bracket,
available separately)
2.2 Mechanical
Display
6-digit LCD, 5 mm high
Range & Resolution
700, 701, 732 Hour Meters: 99,999.9 Hours
703 Counter: 999,999 Counts.
Case & Connector Specifications
