Curtis 700 series Manual

8 9
Operating Current
(All models except 732)
The maximum operating current at terminal 1
is tabulated below for each nominal operating
voltage limit.
DC Only Model
DC/AC Model
VDC: Same as above.
Operating Voltage
(VDC) V+ to V++
Maximum Current
@ V+
Maximum Current
@ V++
5 to 12 0.5 mA 10.0 mA
12 to 48 0.8 mA 5.0 mA
48 to 150 0.8 mA 2.5 mA
Operating Voltage
(VAC) V+ to V++
Maximum Current
@ V+
Maximum Current
@ V++
6 to 12 0.7 mA 6.0 mA
20 to 60 0.5 mA 2.5 mA
100 to 230 0.9 mA 2.0 mA
Operating Current continued
(732 Model only)
Single Voltage, DC only
Operating Voltage (VDC) Maximum Current w/LED (mA)
12 15.0
24 10.0
36 7.0
48 5.0
Voltage
Encodement
Impedance (Min)
Terminal 3
Impedance (Min)
Terminal 4
0512D 10 KΩ 25 KΩ
1248D 60 KΩ 70 KΩ
48150D 480 KΩ 480 KΩ
0512D 0612A 10 KΩ 25 KΩ
1248D 2060A 70 KΩ 70 KΩ
48150D 100230A 480 KΩ 480 KΩ
732 (all voltages) – 70 KΩ
Impedance
The minimum impedance at terminal 3 and at terminal 4
are tabulated below for each model.
