Curtis 700 series Manual

6 7
2. TECHNICAL SPECIFICATIONS
2.1 Electrical
Operating Voltage 700 Series
The operating voltage ranges specified apply to voltages
connected between terminal 1 and terminal 2 (700,
701, 703), terminal 3 and terminal 2 (701,703 only), and
terminal 4 and terminal 2 (Reset option).
DC only models
DC/AC models
Nominal (VDC) / Absolute (VDC) : Same as above
Nominal (VDC) Absolute (VDC)
5 to 12 4.75 to 15
12 to 48 9.0 to 60
48 to 150 36 to 185
Nominal (VAC) Absolute (VAC)
6 to 12 5.0 to 15
20 to 60 15 to 75
100 to 230 75 to 270
Operating Voltage 732 Only
Voltages connected between pins 1 and 2 and
between 4 and 2 (Enable option).
732 DC only, all voltage models
LED voltages betweeen pins 3 and 2.
Frequency (AC models)
The AC operating frequency range is 48 to 440 Hz.
Maximum AC-Reset Frequency is 150 Hz.
Accuracy
Model 700, 701, 732 = ±0.1%
Model 703 = ±1 count
Nominal (VDC) Absolute (VDC)
12 to 48 9.0 to 60
732 LED Voltage Absolute (VDC)
12 9 to 15
24 18 to 30
36 27 to 45
48 36 to 60
