3. INSTALLATION
V+: Operating voltage;
V–: Common (ground);
I: Enable (optional, use operating voltage to power this pin
to record elapsed time [701] or increment count [703]);
R: Reset (optional, supply with operating voltage when
unit is to be reset to 0);
LED: Externally driven by active high or low – factory
configured;
NC: No connection;
2.3 Environmental
Temperature
Operating: –40°C to +85°C
Storage: –50°C to +90°C
Humidity
95% RH (Non Condensing) at 38°C
Shock & Vibration
Meets SAE J 1378
Case - IP Ratings
Case Style D, Q, R F, Z, N G, J, Y, H, K L
Front 65 65 65 65
Rear 50 65 *65 40
* Rated with mating connector installed
Case Style Pin 1 Pin 2 Pin 3 Pin 4
D, F, Q, R, J, Y, Z V+ V– I R
G, H V+ V– NC NC
L V+ V– I NC
K, N V+ V– LED I
