#538'0*6-337.2,
The following checklist should help you to
troubleshoot any problems with the instrument.
53'0*1 366.'0*&86*6
No display Terminals not connected or
improper voltage
Stays at FULL Instrument voltage does not
match battery voltage,
B+ connected to the wrong
terminal
Will not reset Instrument voltage does not
match battery voltage, or battery
not fully charged
Resets w/o charging battery Not connected directly to
battery terminals
EMPTY too soon B+ connected to wrong terminal,
or instrument voltage does not
match battery voltage, or
terminals not directly connected
to battery
&.27*2&2(*
Model 803 Series is not serviceable in the field. Units returned
to the factory within the warranty period (see inside backcover)
will be replaced without charge.
37*6
This equipment is intended to be used on battery
powered industrial vehicles such as Lift Trucks
(Forklifts), Pallet Trucks, and Scrubbers.
If the equipment is used in a manner not specified
by the manufacturer, the protection provided by the
equipment may be imparied.
Direct Current
Reinforced Insulation
