B+ HIGH (Pin 8) Current B+ LOW (Pin 7) Current
Model
Voltage
Output
Option
I Nominal
@B+=Nom
I Maximum
@B+=Max
I Nominal
@B+=Nom
I Maximum
@B+=Max
Dual
Voltage
Untis
12/24V G/Z 26mA@24V 39mA@30V 61mA@12V 120mA@15V
24/36V J 34mA@36V 48mA@45V 27mA@24V 42mA@30V
24/36V K/Y 49mA@36V 67mA@45V 33mA@24V 52mA@30V
24/48V J 34mA@48V 48mA@60V 27mA@24V 42mA@30V
24/48V K/Y 47mA@48V 64mA@60V 33mA@24V 52mA@30V
36/48V J 35mA@48V 48mA@60V 29mA@36V 42mA@45V
36/48V K/Y 44mA@48V 60mA@60V 34mA@36V 50mA@45V
72/80V J 30mA@80V 40mA@100V 28mA@72V 38mA@90V
72/80V K/Y 33mA@80V 45mA@100V 29mA@72V 41mA@90V
#" #"
0*(75.(&0
Operating Range
± 25% of nominal voltage
B+ HIGH (Pin 8) Current B+ LOW (Pin 7) Current
Model
Voltage
Output
Option
I Nominal
@B+=Nom
I Maximum
@B+=Max
I Nominal
@B+=Nom
I Maximum
@B+=Max
Single
Voltage
Untis
12V J 35mA@12V 59mA@15V N/A N/A
24V K/Y 34mA@24V 53mA@30V N/A N/A
