User manual Curtis G3 Series Alpha
Appendix: Technical data
Appendix: Technical data
Technical data for coffee machine
External dimensions Width 232mm
Hight 480mm
Depth 514mm
Water tank volume 6.0 litres
Capacity of the warmer 5.7 litres
Brewed fi ll weight approx. 13.6kg
Water connector 3/8“
Water pressure Min: 0.14MPa, Max: 0.62MPa
Min. fl ow rate 3.8 l/min.
Use at elevation above sea level < 2.000m
Nominal power rating 2426W
Power supply 230VAC
50 / 60Hz (1 PH)
On-site fuse 10.6A
Protection class IP X0
Calibration pressure Boiler 0.32MPa (3.2bar)
Continuous sound pressure level
(Lpa)
< 70dB(A)
Ambient temperature +5°C to maximum +35°C
(empty the water system in case of frost).
Maximum humidity 80 % relative humidity without condensation.
Do not use device outdoors.
Installation surface/water spray The device must be placed and leveled on
ahorizontal, sturdy, water-resistant, and
heatproof base.
The device must not be cleaned using awater
jet. The device must be installed where it is
protected against water spray. The device must
not be located on asurface that is sprayed or
cleaned with awater hose, steam jets, steam
cleaner, or similar devices.
