User manual Curtis G3 Series Alpha
Appendix: Technical data
Installation clearances For operating, service, and safety reasons the
machine should be installed with aclearance
from the building or non-Curtiscomponents of
not less than 50mm at the sides and 50mm at
the back.
A minimum working space of 800mm in
front of the coffee machine is recommended.
Clearance of at least 200mm above the product
hopper is recommended.
A clear height of 1,100mm from the top of the
supporting surface should be ensured.
The height of the installation surface
above the fl oor should be at least 700mm
and max.900mm. If the coffee machine
connections are to be run downwards through
the counter, please make space for the lines,
which can reduce the usable space below the
machine.
We reserve the right to make technical modifi cations.
