Curtis G4 Series User Manual

ILLUSTRATED PARTS/RECOMMENDED PARTS IP3
G4CBHS/G4CBHT, ILLUSTRATED PARTS/RECOMMENDED PARTS 092818D
ITEM # PART # DESCRIPTION
1 WC-58117
COVER, TOP ALPGT/D500GT/D60GT TLP/TCTS/CBS/
GEMSS
2 WC-61607 COVER, FRONT CBHVS
3 WC-8531 RAIL, BASE TCTD
4A
1
WC-2977K KIT, SPRAYHEAD FITTING METAL
4B
2
WC-2977-101K KIT, SPRAYHEAD FITTING PLASTIC
5 WC-29044-101 SLEEVE, OVERFLOW
6 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
7 WC-820WDR
VALVE, DUMP RIGHT 120V 12W W/INTERNAL RESIS-
TOR & DIODE
8 WC-844-101
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
9 WC-895-105 VALVE, INLET DUAL 120V 10W 2 GPM X .5 GPM
10 WC-37255 KIT, DUAL VALVE WATER INLET
11 WC-3417-P
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
12 WC-3398
BREW CONE, ASSY STD TEA NON METAL W/BLU
SPLASH POCKET
13 WC-3422IC
BREW CONE,ASSY W/SPLASH POCKET TAN STYLZD
HV ‘ICED COFFEE’
14 WC-66079 SPOUT ASSY , DILUTION PLASTIC
15 WC-43134 O’RING, .426 X 9/16 O.D X .070 WALL EDPM TCTS
16 WC-13463-102 HARNESS ASSY, COMPLETE G4CBHS
17 WC-10000 CONTROL MODULE, TOUCH SCREEN G4
18 WC-10001 CONTROL MODULE, UPM 120/220V G4
19 WC-10008 UNIVERSAL HOST ADAPTER USB
20 WC-103
SWITCH, TOGGLE NON-LIT DPST 25A 125/250VAC
RESISTIVE
21 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
22 WC-8559
RELAY, SOLID STATE 280V/40A W/HEAT SINK AND
QUICK DISCONNECTS
ITEM # PART # DESCRIPTION
4A WC-2977K KIT, SPRAYHEAD FITTING METAL
6 WC-29050 SPRAYHEAD, AMBER ADVANCED FLOW
7 WC-820WDR
VALVE, DUMP RIGHT 120V 12W W/INTERNAL RESIS-
TOR & DIODE
8 WC-844-101
VALVE, BY-PASS, NON-ADJUSTABLE WITH
RESTRICTOR (WC-2945)
10 WC-37255 KIT, DUAL VALVE WATER INLET
G4CBHS - Recommended Parts to Stock
ITEM # PART # DESCRIPTION
23 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
24 WC-5231 COMPOUND, HEAT SINK 5OZ
25 WC-589-101
TRANSFORMER,120VAC-24V 4.8A W/ LEADS &
MOLEX CONNECTOR
26 WC-1501 FUSE, HOLDER ASSY W/5A FUSE
27 WC-1200 CORD, 14/3 SJTO 6’ BLK W/PLUG
28 WC-3503 LEG, 3/8”-16 STUD SCREW BUMPER
29 WC-3518 LEG, GLIDE 3/8”-16 STUD SCREW
30 WC-5350 TUBE, 1/2 ID x 1/8W SILICONE GEN USE
31A
1
WC-4320 O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N #112
31B
2
WC-43089
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE EPDM
70 SHORE
32A
1
WC-4213-P NUT, 5/8 LOCK PLATED
32B
2
WC-4212-02 NUT, 5/8-18 JAM PLASTIC
33 WC-847
VALVE, INLET 2 GPM 120V 10W GEN USE BROWN
BODY
34 WC-12020 VALVE, INLET .5 GPM 120V 9W CB
35 WC-2401-P ELBOW 3/8 NPT X 1/4 FLARE PLTD
36 WC-53169-7
TUBE ASSY, BRAIDED 1/4 FLARE X 6-3/4” LG W/
FITTINGS
37 WC-2705 TEE, 1/4 X 1/4 FLARE X 3/8 NPT PLATED
38 WC-314 POWER BLOCK, 5 STATION
39 WC-37132-101
KIT, VALVE REPAIR FOR DELTROL WC-820WDR,WC-
821WDR, WC-844WDR
40 WC-4458
SCREW, 6-19 x 1/2” PHIL PAN HD TRI-LOBULAR 60-1
THRD FORMING
41 WC-4514 SCREW, 8-32x3/8 PAN HEAD PH SS
42 WC-4426 SCREW, 8-32x3/8 PH HEAD TRUSS
43 WC-4616
SCREW, 1/4-20 x 1/2 PHILLIPS PAN HEAD STAINLESS
STEEL
ITEM # PART # DESCRIPTION
20 WC-103
SWITCH, TOGGLE NON-LIT DPST 25A 125/250VAC
RESISTIVE
22 WC-8559
RELAY, SOLID STATE 280V/40A W/HEATSINK AND
QUICK DISCONNECTS
23 WC-5310 TUBE, 5/16 ID x 1/8W SILICONE
24 WC-5231 COMPOUND, HEAT SINK 5OZ
G4CBHS - Main Chassis - Parts List
1
Units built 05/15/17 and later.
2
8QLWVEXLOWEHIRUH7KHSODVWLFÀWWLQJDVVHPEO\PD\EHUHSODFHGZLWKD
VWDLQOHVVVWHHOÀWWLQJNLWLWHP$%UHZVHWWLQJVIRUWKHXQLWPXVWEHFKDQJHGZKHQ
FKDQJLQJÀWWLQJW\SHV6HHLQVWUXFWLRQVWKDWFRPHZLWKQHZÀWWLQJ
