Curtis G4 Series User Manual

KEY FEATURES/SPECIFICATIONS/SYSTEM REQUIREMENTS FS3
Key Features
• Multiple Beverage Options – Allows you to brew Coffee, Iced Coffee and Iced Tea from one model.
• Generation Four (G4) Digital Control Module – Large, 4.3” touchscreen. Icon-driven interface streamlines
operation. Provides precise control of all critical brewing functions.
• On-Screen Instructions – Provides fast, intuitive training; reduces service calls.
• Built-in Self Diagnostic System – Includes real-time feedback of the brewing process and energy saving mode.
• Industry’s most effective mineral tolerant design.
• Encapsulated control boards – Protect against steam, water and impact.
6SHFLÀFDWLRQV6HOHFWHG0RGHOV
(OHFWULFDO6XSSO\5HTXLUHPHQWV
02'(/ '(6&5,37,21 3+$6( 92/76 $036 +($7,1*&21),* :,5( :$776 +(57= &$3$&,7<
*&%+6
Single, Combo High Volume Brewer 1 PH 120/220 V 15.0/12.7 A 2 X 1600 W 2W/3W + G 1800/2800 W 50/60 Hz
12.0 gal/hr
[45.4 l/hr]
*&%+7 Twin, Combo High Volume Brewer 1 PH 220 V 23.0/34.0 A 3 X 2500 W 3W + G 5100/7500 W 50/60 Hz
21.0 gal/hr
[79.5 l/hr]
'LPHQVLRQV :DWHU6XSSO\5HTXLUHPHQWV
02'(/ +(,*+7 :,'7+ '(37+ 6+,3:(,*+7 6+,3&8%( :$7(5&211(&725 :$7(535(6685( 0,1)/2:5$7(
*&%+6
36.71”
[93.2 cm]
10.07”
[25.6 cm]
22.82”
[58.0 cm]
47.0 lbs
[21.3 kg]
9.27 cu. ft.
[0.26 m
3
]
µÁDUH
20 - 90 psi
[138 - 620 kPa]
1.0 gpm
[3.8 lpm]
*&%+7
36.71”
[93.2 cm]
18.11”
[46.0 cm]
22.82”
[58.0 cm]
76.0 lbs
[34.5 kg]
16.04 cu. ft.
[0.45 m
3
]
µÁDUH
20 - 90 psi
[138 - 620 kPa]
2.0 gpm
[7.6 lpm]
G4CBHS/G4CBHT, KEY FEATURES/SPECS/SYSTEM REQUIREMENTS 092419C
• Brew Temperature = 200°F (92°C)
• Minimum Brew Temperature = 195°F (90°C)
• Water Bypass (coffee) = On LARGE and MEDIUM
brew only
Following are the factory default settings for the combination brewer:
• Brew Volume (coffee) = Large-Medium-Small
• Brew Volume (tea) = Large-Small
• Energy Save Mode = Off
