Curtis Gemini 12D Series User Manual

ILLUSTRATED PARTS LIST IP35
GEM-12D, ILLUSTRATED PARTS/RECOMMENDED PARTS 051618D
ITEM # PART # DESCRIPTION
1 GEM-3 SATELLITE SERVER, 1-1/2 GAL.
2A* WC-821WDR
1
VALVE, DUMP LEFT 120V 12W W/INTERNAL
RESISTOR & DIODE
2B WC-853
2,3
VALVE, BREW DUMP LEFT 240V 12W GEM12D/
TP/TPC
3 WC-1412 CORD GRIP, 3/4” FOR METAL CORD TO .81”OD
4A* WC-2962K
a
KIT, FITTING SPRAYHEAD SS
4B WC-2962-101K
b
KIT, FITTING SPRAYHEAD KYNAR
5 WC-2987
BYPASS ASSEMBLY, ADJUSTABLE (WC-
2984,WC-2985 & WC-43011)
6A WC-37132
KIT, VALVE REPAIR FOR INVENSYS WC-
820WDR,WC-821WDR, WC-844WDR (OLDER
UNITS)
6B WC-37132-101
KIT, VALVE REPAIR FOR DELTROL
WC-820WDR,WC-821WDR, WC-844WDR
(NEWER UNITS)
7A WC-670
1
CONTROL BOARD 120V 50/60HZ GEM-12D
7B WC-758
2,3
CONTROL BOARD 220V 50/60HZ GEM12D-30
8 WC-5423
DECK, WARMER W/ASSY GEM12
312IL/612IL/12ILD/612ILD
9* WC-29025 SPRAYHEAD, PURPLE ADVANCE FLOW
10A* WC-8560
1,3
HEATSINK, ASSY 1PH GEM612ILD GEM-12D/
TL9002-10/D1000AP/T
10B WC-8557
2
HEATSINK, ASSY 3PH TL9002/GEM-12D/612ILD
11* WC-3417-P
BREW CONE,ASSY W/SPLASH POCKET BRWN
STYLIZED GEMIN HOT COFFEE
12 WC-39198
LABEL, BOTTOM PANEL GEM12D/612 ILD
CURTIS
13 WC-5829
COVER, FRONT W/A GEM-12 GEM-
12D/312IL/612ILD
14 WC-39197 MEMBRANE CONTRL PANEL CURTIS GEM-12D
15 WC-38310 LABEL, CAUTION HOT SURFACE GEN USE
16A WC-5430
1
WARMER DECK, COMPLETE W/WARMER
ELEMENTS GEM-12,312IL
16B WC-37163
2,3
KIT, WARMER ELEMENT 100W 220V GEN USE
17 WC-29044-101 SLEEVE, OVERFLOW
18* WC-2402P-P ELBOW, 3/8”FL x 3/8” NPT PLATED
19A* WC-847
1
VALVE, INLET 2 GPM 120V 10W GEN USE
BROWN BODY
19B WC-883
2,3
VALVE, INLET 2 GPM 240V 6W
20A* WC-820WDR
1
VALVE, DUMP RIGHT 120V 12W W/INTERNAL
RESISTOR & DIODE
20B WC-854
2,3
VALVE, BREW DUMP RIGHT 240V 12W GEM12D/
TP/TPC
ITEM # PART # DESCRIPTION
21* WC-1501 FUSE, HOLDER ASSY W/5A FUSE
22A* WC-102
1
SWITCH, TOGGLE NON-LIT SPST 15A 125/6A
250VAC RESISTIVE
22B WC-103
2,3
SWITCH, TOGGLE NON-LIT DPST 25A
125/250VAC RESISTIVE
23 WC-5421
COVER, TOP SS GEM-12D GEM-
612ILD,TL9002,312IL
24* WC-3528
LEG, 4” ADJUSTABLE 3/8-16 THRD ITALIAN
STYLE
25A* WC-1809
1
FAUCET, PS/HPS SERIES HOT WTR 1/2-20 UNF
AP/ALP
25B WC-2912BK
4
SPOUT, HOT WATER “NO SPLASH”
26* WC-5310 TUBE, 5/16 ID x 1/8W SILICONE GEN USE
27* WC-5231 COMPOUND, HEAT SINK 5OZ
28A WC-37102
1
KIT, WARMER ELEMENT 100W 120V GEN USE
28B WC-37163
2,3
KIT, WARMER ELEMENT 100W 220V GEN USE
29 WC-892
4
VALVE, HOT WATER 220V 17W GEM-12D
30A WC-13256
1
HARNESS, ASSY GEM-12D-10 (INCLUDES
TERMINAL BLOCK)
30B WC-13372
2
HARNESS, ASSY GEM-12D-16 (INCLUDES
TERMINAL BLOCK)
30C WC-13350
3
HARNESS ASSY, TLPGT 120V (INCLUDES
TERMINAL BLOCK)
31 WC-1250
3
CORD, 4mm² 90ºC 49A 450/750V 6 FT LG W/
FERRULES ONE END (NOT SHOWN)
32A WC-4320
a
O’RING, 0.487I.D.x 0.693OD x0.103CS BUNA-N
#112
32B WC-43089
b
GASKET, 1.00OD X .625 I.D. X .030 THK WHITE
EPDM 70 SHORE
33A WC-4213-P
a
NUT, 5/8 LOCK PLATED
33B WC-4212-02
b
NUT, 5/8-18 JAM PLASTIC
34 WC-314 POWER BLOCK, 5 STATION
35 WC-1806 SEAT CUP, SILICONE USE ON WC-1809 FAUCET
36 WC-4426 SCREW, 8-32x3/8 PH HEAD TRUSS
37 WC-4616
SCREW, 1/4-20 x 1/2 PHILLIPS PAN HEAD
STAINLESS STEEL
GEM-12D - Main Chassis - Parts List
1
GEM-12D-10,
2
GEM-12D-16,
3
GEM-12D-30
4
Used on units manufactured before 4/12, equipped with an electric faucet.
a
8QLWVEXLOWDQGODWHU6WDLQOHVVVWHHOÀWWLQJNLW$LVFRPSDWLEOHZLWKROGHUXQLWV
b
Units built before 05/15/17.
5HFRPPHQGHGSDUWVWRVWRFN
