MA6B Parts List:
[X] Quan Part # Description .
[ ] 2 MT1 21/28 MHz driven element trap assembly
[ ] 4 MT2 24.9 MHz trap assembly
[ ] 2 MT3 21/28 MHz reflector element trap assembly
[ ] 1 80-MN6B-MB Feed network with coax cables
[ ] 2 MA5BEF Element Tube, 1-1/8" OD x 84", slotted both ends
[ ] 2 MA5BEE Element Tube, 7/8" OD x 12", slotted one end
[ ] 2 MA5BED Element Tube, 1-1/8" OD x 46", slotted one end, drilled other end
[ ] 4 MA5BEC Element Tube, 7/8" OD x 7" slotted one end, drilled other end
[ ] 2 MA5BEJ Element Tube, 7/8” OD x 13-1/2 slotted one end, drilled other end
[ ] 6 MA5BEB Element Tube, 1" OD > 7/8" OD (swaged) x 36", slotted one end
[ ] 2 MA5BEA Element Tube, 1-1/8" OD x 34", slotted one end, drilled other end
[ ] 2 MA5BEG Element Tube, 1" OD > 7/8" OD, (swaged) x 41-1/2", slotted one end
[ ] 2 20-MA6B-DD Element Tube, 7/16" OD x 48", drilled one end, slotted other end
[ ] 2 20-MA6B-DE Element Tube, 3/8" OD x 9"
[ ] 1 20-MA6B-EG Element Tube, 7/16” OD x 72", slotted both ends, drilled at center
[ ] 2 20-MA6B-EH Element Tube, 3/8" OD x 28"
[ ] 2 20-MA6B-BC Boom Tube, 1-1/2" OD x 48", slotted one end
[ ] 1 20-MA6B-BD Boom Tube, 1-1/2" OD x 21", slotted both ends
[ ] 1 20-MA6B-BE Boom Tube Insert, 1-3/8" OD x 48"
[ ] 2 735-1106 Element Mounting Bracket, 6M driven element
[ ] 2 205560-1 Insulating plate, 6M driven element
[ ] 2 193-853 90-degree mounting bracket for insulating plate
[ ] 1 738-1213 Reflector insulating plate, ¼” x 2-1/2” x 3-1/2”
[ ] 1 735-1109 “L”-mounting bracket for reflector insulating plate
[ ] 16 HXR41 41" X-hat rod
[ ] 8 HXR26 26" X-hat rod
[ ] 2 HXR24 24" X-hat rod
[ ] 1 240116 Silicone grease packet
[ ] 1 050115 UHF connector boot, black
[ ] 28 190028 X-hat Half-washer
[ ] 26 190026 X-hat Element bracket
[ ] 4 190033 U-Bolt Backing plate for elements
[ ] 4 190143 Element-to-Boom clamp
[ ] 4 190033 U-bolt backing plate
[ ] 1 758-9200 1/4”-20 x 2-3/4” U-bolt assembly
[ ] 4 010402 1/4"-20 x 1-1/2" ID x 3-3/4" U-bolt
[ ] 10 010085 1/4-20 Hex nut
[ ] 10 010084 1/4" Split lock washer
[ ] 1 190070 Boom-to-Mast clamping plate
[ ] 2 010403 5/16-18 x 1-5/8" x 3" U-bolt
[ ] 2 010404 5/16-18 x 2-1/8" x 3-1/4" U-bolt
[ ] 8 010119 5/16 split lock washer
[ ] 8 010118 5/16-18 Hex nut
[ ] 2 122096 Fiberglass driven-element insulator, 1" OD x 10"
[ ] 1 030413 Worm clamp, 1-1/2 to 1-3/4"
[ ] 4 030412 Worm clamp, 1-1/4" to 1-1/2"
[ ] 8 030411 Worm clamp, 1" to 1-1/4"
[ ] 16 030410 Worm clamp, 7/8" to 1"
[ ] 4 030407 Worm clamp, 3/8 to 1/2”
[ ] 2 050046 1-1/2" Plastic end cap, for boom
[ ] 8 050061 7/8" Plastic end cap for HF elements
[ ] 4 050251 3/8" Plastic end cap for 6M elements
[ ] 46 010941 #8 Lock washer
[ ] 46 010011 8-32 Nut
[ ] 6 010079 1/2" x 8-32 Screw
[ ] 4 010072 3/4” x 8-32 Screw
[ ] 2 010229 1" x 8-32 Screw
