Cushman Shuttle 6 - Page 192

Page S-6
Repair and Service Manual
B
GENERAL SPECIFICATIONS
Read all of Section B and this section before attempting any procedure. Pay particular attention to Notices, Cautions, Warnings and Dangers.
RECOMMENDED
MAX RAMP GRADE
25% or 14° MAX
RECOMMENDED MAX SIDE TILT
25% or 14° MAX
48.6 in.
(123.0 cm)
72.0 in.
(183.0 cm)
Rear Wheel Track
38.0 in. (97 cm)
Front Wheel Track
34.2 in. (86.7 cm)
