Summary
The VLCD-5 display is an intelligent management system for electric bikes. It’s mainly used to control
the power assistance, show the battery level, measure the speed of electric bicycle and record the trip
distance.
Specification
Type
VLCD-5
Working voltage
DC 11V-60V
Max working current
70mA(11V) 32mA(50V)
Display type
(21*4 segment LCD)
Measuring the speed
1-12 pulses each round of wheel
Working temperature
-20
0
C—+70
0
C
Backlight
(White LED mode，brightness:200cd/m
2
)
Dimension
102.5mm×74.5mm×28mm
(102.5mm×75.5mm×28mm (exclude thickness of Pedestal)
