ASSEMBLY & ADJUSTMENTS
WARNING! MAKE CERTAIN THAT THE MACHINE IS DISCONNECTED FROM THE
POWER SOURCE BEFORE ASSEMBLY AND ADJUSTMENTS
FENCE ASSEMBLY PROCEDURE
1. Face the rear of the jointer and remove the 4 screws (A) using the provided 4mm Hex Wrench.
See FIG 1
2. Using the provided 4mm Hex Wrench, install Fence Bracket (D from Inventory page 12) using
the 4 screws removed in the previous step. Tighten screws securely. See FIG 2
