9.b. Battery Remote System – Fault Diagnosis
This fire is operated via a battery remote system with AA batteries. The
remote system has a built in alarm system which indicates and faults which
may arise. This is shown by a sequence of a pre-defined number of “beeps”
corresponds to a certain failure. NOTE: There are two types of black box fitted
to this type of appliance. See the black box to identify which one is fitted to
your fire.
BLACK BOX – IR/RF
Alarm sound description
7 x beeps – Low Battery
Substitute the battery with a new one and verify the sound alarm stops.
Before inserting the new battery pack, remove the old one and wait until the
sound disappears. Wait at least 2 minutes before adding the new batteries. If
the sound is still present after adding new batteries, execute an ignition
sequence.
3 x beeps – Manual Wall Switch Keyboard Failure
Substitute the keyboard with another one and verify the sound alarm stops.
4 x beeps – Valve Motor Failure
Substitute the valve with another one. Repeat the ignition sequence and
verify the sound alarm stops.
5 x beeps – Driver Leakage [Black Box Faulty]
Substitute the board: the motor drive circuit is damaged. Execute an ignition
sequence and verify there’s no sound alarm.
6 x beeps – Under Voltage Low battery
Substitute the battery with a new one and verify the sound alarm stops.
Before inserting the new battery pack, remove the old one and wait until the
sound disappears. Wait at least 2 minutes before adding the new batteries. If
the sound is still present after adding new batteries, execute an ignition
sequence.
